The motor plug should not be used to start stop the equipment.
The electrical feeding cable should not be used to remove the plug from the socket.
MAKE SURE that the electrical cable is with the proper section and functioning properly.
Before doing any type of repair, DISCONNECT the motor from the electrical system.
When connecting to a generator, MAKE SURE that the out tension and frequency is stable, right,
and has the proper power, (the converter's feeding voltage should not vary more than ± 5% as
stated on the motor's plate).
When finishing the job or when taking a break, the operator SHOULD UNPLUG, disconnect it from
the electrical system, and have it placed in such a way that it should not fall or tip

4.7 PERSONAL PROTECTIVE EQUIPMENT

Use approved protective equipment. Operators and all other persons in the working
area must wear protective equipment:
Helmet, hearing and eye protection, gloves and boots.
5

USAGE CONDITIONS

For your own safety, as protection for others, and to avoid damage to the equipment, read carefully
the usage recommendations.
1. Before working, to be sure the hose joint nut is fastened to the motor (screwed to left).
2. Be sure the poker is well screwed to the flexible shaft (screwed to left).
3. Do not work with flexible shaft with big bends.
4. Do not overlubricate the shaft.
5. Do not keep working the poker out of the concrete more than 5 minutes.
6. Do not restrict the movement of the poker during the work.
7. Do not stop the poker inside the concrete.
8. Change the wear parts to avoid damage to the internal parts. (Check wearing table for the poker)
9. Do the maintenance with the kinds and quantities of recommended lubricants.
IN ADDITION, LOCAL COUNTRY ESTABLISHED ORDINANCES SHOULD BE RESPECTED.
6

OPERATION AND MAINTENANCE

6.1 GETTING STARTED
Read item 5 USAGE CONDITIONS
6.2 SHAFT CONECTION TO POWER UNIT
Power unit is designed to facilitate a quick and safe connection to flexible shaft.
CONNECTION PROCEDURE:
1. Introduce power unit hexagonal axle into the provided shaft housing
2. Screw plastic nut of shaft to aluminium thread of power unit . (Be aware of nut turns left and not
tool is required)
CONNECTION CHOICES :
FLEXIBLE SHAFT LENGTH:
VIBRATOR DIAMETER:

6.3 ELECTRIC MOTOR CONECTION TO THE SYSTEM

Turn off the motor switch before connecting it.
AVMU MOTOR - FLEXIBLE SHAFT AND POKERS
TAX1m, TAX1-5m, TAX2m, TAX3m, TAX4m, TAX5m, TAX6m
TO 6 MTS (TAX1M, TAX1,5M,TAX2M, TAX3M, TAX4M, TAX5M,
TAX6M)
TO 58 MM DIAMETER (AX25, AX32, AX40, AX48 AND AX58)
AVMU - AX25, AX32, AX40, AX48, AX58
