CONFIGURATION HOME
PAGE MENU
Visualization
ENGLISH
SYSTEM CONFIGURATION WITH TECHNICAL PASSWORD: 31100
(SET INVERTER MENU).
Viewing page of the configuration menu.
1: Set plant
2: Set inverter
3. Set inputs outputs
4: Managing Alarms
5: Electrical values
6: Software version
To enter the page of the menus press the button SB9
password.
Type in the user password 31100 and enter in the menu SET plants listed below.
Press SB6 –SB7
Press SB8 –SB10
Press SB9
to confirm the data.
Press SB1
to return to the HOME PAGE monitor
Submenu SET INVERTER parameter
Description
2.1 Motor power
Data plate value of the motor rated power, in
kW.
2.2 Motor voltage
Data plate value of the motor rated voltage, in
V.
2.3 Motor frequency
Data plate value of the motor rated frequency,
in Hz.
2.4 Inverter current
Data plate value of the inverter rated current in
A.
2.5 Motor speed
Data plate value of the motor rated speed, in
min-1.
2.6 Modulation frequency
Choice of PWM modulation frequency of the
output voltage.
1
1
to scroll through pages of parameters.
2
2
to decrease or increase the data.
depends on the
of the panel
depends on the
of the panel
1450 - 2950
04 -:- 16 kHz
54
appears the page insert
Field
Default
depends on the size
size
of the panel
400 V
400 V
050 Hz
060 Hz
depends on the size
size
of the panel
2900 min-1
min-1
08 kHz
50 Hz
