2.7.4 Menu HART – Modèle 700
1 PV
2 PV Loop Current
3 PV % Range
4 Device Setup
1 Identity
5 Setup Wizard
6 Diagnostics
7 Measured Values
1 Level
2 Ifc Level
3 Upr Thickness
4 Volume
2 Basic Config
5 Flow
6 Head
7 Distance
8 R Totalizer Value
9 NR Totalizer Value
10 Echo Strength
11 Ifc Echo Strength
12 Buildup
13 Temperature
3 Volume Config
4 Flow Config
5 I/O Config
6 Local Display Config
7 Advanced Config
8 Factory Config
32
1 Enter Password
2 Tag
3 Long Tag
4 Descriptor
5 Date
6 Message
7 Date/Time/Initials
8 Factory Identity
1 Manufacturer
2 Product Name
3 Magnetrol S/N
1 Enter Password
4 Hardware Version
2 Level Units
5 Firmware Version
3 Probe Model
6 ConfigChg Counter
4 Probe Coating
7 Final Assy Number
5 Probe Mount
8 Device ID
6 Probe Length
9 Universal Revision
7 Measurement Type
10 Field Device Revision
8 Level Offset
11 Software Revision
9 Dielectric Range
12 Num Preambles
10 Upper Dielectric
11 Basic Config Diagram
1 Enter Password
2 Volume Units
3 Vessel Type
4 Length
5 Width
6 Radius
7 Ellipse Depth
8 Conical Height
9 Table Type
10 Vessel Diagrams
11 Custom Table Type
12 Level Input Source
13 Custom Table Length
1 Enter Password
14 Custom Table
2 Flow Units
3 Flow Element
4 Flume Channel Width
5 V-Notch Angle
6 Crest Length
7 Custom Table Type
8 Reference Distance
9 Maximum Head
10 Maximum Flow
11 Low Flow Cutoff
12 General Equation
Factors
13 Flow Diagrams
1 Enter Password
14 Custom Table
2 PV is
15 Totalizer Setup
3 Lonwer Range Value
4 Upper Range Value
5 Analog Alarm Selection
6 Damping
7 I/O Config Diagram
8 Variable Selection
1 SV is
9 Set Points 2 TV is
3 QV is
1 Lvl 4mA Set Point
2 Lvl 20mA Set Point
3 Ifc 4mA Set Point
4 Ifc 20mA Set Point
5 Thk 4mA Set Point
6 Thk 20mA Set Point
7 Vol 4mA Set Point
8 Vol 20mA Set Point
9 Flo 4mA Set Point
10 Flo 20mA Set Point
1 K
2 L
3 C
4 n
1 Totalizer Units
2 NR Mult
3 NR Totalizer Value
4 NR Totalizer RunTime
5 R Totalizer Mode
6 R Totalizer Mult
7 R Totalizer Value
8 R Totalizer RunTime
9 Totalizer
