Operating instructions SATAjet RP (DIGITAL 2)

8. Spare parts

Part.No. Description
1503 Countersunk screw M4 x 8 DIN 965
1826 Pack of 4 pcs. non-drip devices
3657 Control knob
3988 Paint strainers, pack of 10 pcs.
6213 Trigger set for SATAjet
7757 * 1 Pack of 4 CCS-Clips
9050 Tool set
10520 Pack of 12 springs for paint needle (17897)
14985 Battery cpl. with compartment lid and sealing
15438 Fluid needle packing
16162**** Swivel joint complete (for SATAjet RP DIGITAL 2)
17152 Pack of 12 air piston springs (27813)
19745**** Swivel joint complete (for SATAjet RP)
26518 Adjust material flow control
27243 Plastic cup, 0.6 l, QCC for quick change
49395 Screw-on lid for 0.6 l plastic cup
57620 ( ) Repair kit SATAjet
76018 Pack with 10 x 10 paint strainers
76026 Pack with 50 x 10 paint strainers
82552 ( ) Air piston service unit

86843 Air piston rod
89771 Spindle cpl. for round/flat spray control
94961 Air micrometer
95091 Air connection piece (for SATAjet RP DIGITAL 2)
97824 Pack of 3 air distribution rings
133926 Trigger sleeve set
133934 Pack of 3 sealings for spindle round/flat spray control
133942 Seal retainer, cpl.
133959 Spring set for SATA paint spray guns w. 3 x paint needle/air
piston
springs each
133967 Pack of 3 fixing screws for SATA air micrometer
133983 Air connection piece G 1/4 ext.
133991 Pack of 3 air piston heads
134098 Air connection piece G 1/4 ext. - M15 x 1 ext.
* 1 According to spray gun type without CCS
**** Swivel joint only available with gravity cup guns
The spare part drawings and the accessories can be found on
the fold-out page at the end of this booklet
IX.9
