2 ARMS
2.8

Replacing Armrest Arm Pad

For this procedure, refer to FIGURE 8.
1.
Remove the armrest from the wheelchair. Refer to Removing/Installing and Adjusting T-Arms on page 47 or Adjusting the Height, Depth, and
Angle of the Comfort Arm on page 53.
2.
Remove the mounting screw(s) (A) that secure the arm pad (B) in place.
3.
Replace arm pad and securely tighten with the existing mounting screws.
4.
Install the armrest onto the wheelchair. Refer to Removing/Installing and Adjusting T-Arms on page 47 or Adjusting the Height, Depth, and Angle
of the Comfort Arm on page 53.
Invacare® MyOn
56
Part No 1167417
