Sunrise Medical QUICKI Attitude Notice D'utilisation page 11

Fig.4.6
Docking top Docking bottom
position 1 position 1
position 1 position 1
position 1 position 1
position 1 position 1
position 1 position 1
position 1 position 1
position 2 position 2
position 2 position 2
position 2 position 2
position 2 position 2
position 2 position 2
position 2 position 2
Frame angle: 95°
Seat depth: 440 mm
Seat height rear: 450 mm
Seat height front: 500 mm
COG:
Attitude/Attitude Hybrid Rev.2.0
(X) mm
640
650
660
670
680
690
660
670
680
690
700
710
80 mm
S = 25 mm
B
(Y) mm (S) mm
370 25
370 25
370 25
370 35
370 35
370 35
365 15
365 25
365 25
365 25
365 25
365 35
A
(a) mm (L) mm
75 - 95 35
75 - 95 38
75 - 95 41
75 - 95 44
75 - 95 47
75 - 95 50
75 - 95 36
75 - 95 39
75 - 95 42
75 - 95 45
75 - 95 48
75 - 95 51
11
