Service Menu

The Service Menu is accessed by turning the selector (detail 3 - fig. 1) to RESET for 10 seconds and then to
or (summer). "tS", "In", "Hi" or "rE can be selected byfig. 1means of the heating knob (detail 1 - ). "tS" means Trans-
parent Parameters Menu, "In" Information Menu, "Hi" History Menu, and "rE" History Menu Reset. After selecting the
Menu, to access it turn the selectorfig. 1(detail 3 - ) to RESET for 1 second and then to
"tS" - Transparent Parameters Menu
The card is equipped with 24 transparent parameters also modifiable from the Remote Timer Control (Service Menu):
Table. 2
Remote Card Description of Transparent Parameters
Control
01 P01 Gas type selection
02 P02 Not used
03 P03 Absolute min. power
04 P04 Lighting power
05 P05 Not used
06 P06 Heating train
07 P07 Heating pump
Post-Circulation
08 P08 Heating standby time
09 P09 Max. heating power
10 P10 Pump operation
11 P11 Pump deactivation temperature during Post-Cir-
culation
12 P12 Heating user max. setpoint
13 P13 DHW pump Post-Circulation
14 P14 DHW standby time
15 P15 DHW max. power
16 5.4P16 DHW user max. setpoint
17 P17 Comfort activation temperature
18 P18 Comfort deactivation hysteresis
19 P19 Burner shutdown in hot water production
20 P20 Not used
21 P21 Not used
22 P22 Not used
23 P23 Not used
24 P24 Mains Voltage Frequency
Thefig. 1list of parameters can be scrolled, in increasing or decreasing order, by means of the heating knob (detail 1 -
). To change the value of a parameter just turn the DHW knob (detail 2 - fig. 1): the change will be automatically saved.
To return to the Service Menu just turn the selector ((detail 3 - fig. 1) to RESET for 1 second
or (summer). Card Service Menu exiting occurs by turning the selector (detail 3 - fig. 1) to RESET for 10 seconds
and then to (winter) or
