Indication during operation
Heating
A heating demand (generated by the Room Thermostat or Remote Timer Control) is indicated by lighting up of the ra-
diator (detail 5 - fig. 1).
The multifunction display (detail 9 - fig. 1) shows the heating sensor temperature.
Domestic hot water (DHW)
A DHW demand (generated by drawing domestic hot water) is indicated by lighting up of the tap (detail 6 - fig. 1).
The multifunction display (detail 9 - fig. 1) shows the DHW sensor temperature.
Comfort
A Comfort demand (restoring the temperature inside the boiler) is indicated by lighting up of the tap (detail 6 - fig. 1).
The multifunction display (detail 9 - fig. 1) shows the heating sensor temperature.
