Instructions for use for the user
The evaporator (humidity function B) can only be started when the sauna
heater (temperature function A) is switched on. The maximum humidity
level which can be set depends on the temperature of the sauna. The
higher the sauna temperature, the lower the maximum humidity level
which can be set.
Exception: Evaporator single mode is activated (see "8.2. Settings
in the technician menu" on page 29). The evaporator can also be
operated here without the sauna heater, with the maximum humidity
depending on the current sauna room temperature.

10.5. Starting additional output

Infrared lamps, or infrared heat plates, for example, can be connected to the
additional output on the sauna control unit.
WARNING!
Risk of fire
Flammable objects that are placed on or in front of the infrared lamp
could ignite and cause fires.
● NEVER place flammable objects on or in front of the infrared lamp.
● Make sure that NO flammable objects have been placed on or in front
of the infrared lamp before you switch it on.
Two different modes are available for the additional output:
1. Intensity regulation
2. Room temperature regulation
You can switch between the two modes as follows:
1. Turn the function selector 2 to position C (additional output).
► The additional output symbol lights up.
► In the intensity display 4, either an intensity value or the temperature
are displayed, depending on the mode.
p. 38/54
