Installation instructions, only for experts

5.12. Status output

Any electrical device can be connected to the status output terminal which is
suitable for 24 V DC voltage and draws a current no greater than 200 mA. Make
sure the polarity is correct when connecting a device. When LEDs are used,
a suitable series resistor must be used.

5.13. Finishing installation

1. Connect the earth conductor for the power supply cable and all devices to
the earth rail g.
2. Place the cover of the housing on the upper edge of the junction box.
3. Push the clip locks inwards lightly, and turn the cover of the housing down-
wards until it engages audibly.
