Item Description
1 Main switch
2 On/Off switch
3 Signal light
4 Connection socket
5 Connection socket
6 Connection socket
7 Connection socket
8 Connection socket

6.3 Positioning the extraction hood

The extraction arm or extraction hood is designed in such a way that it can
be adjusted and moved easily by hand. Once it has been positioned, the
extraction hood maintains its set position of its own accord. Furthermore,
both the extraction hood and the arm can be pivoted through 360° so that
almost any position can be set. It is important that the extraction hood is
always positioned properly in order to achieve adequate capture of the
welding fumes. The correct position is shown on the following image.
1502518-00
Function
Disconnects the power supply completely
from the mains.
Switches the product on or off.
Even if the product is controlled with
automatic start/stop or at the switch on the
hood, the on/off switch must be actuated in
advance.
Indicates the need for maintenance
Control lead
Motor lead
Mains supply connection cable
Automatic start/stop
Lighting and on/off in the extraction hood
(optional extensions)
Tab. 28: Operating control
