Dolby Digital 2.0 discs
7
COP
Dolby Digital decoding is auto-detected and
cannot be overridden. You may, however, select
2-channel playback, 5.1 channel playback with
Pro Logic II matrix surround, 6.1/7.1 channel
playback with Pro Logic IIx matrix surround,
or Dolby 3-Stereo playback.
• On a 5.1 system. Press the SUR+ button
on the remote, then use the +/– buttons to
step through four optons: DD 2.0 channel,
DD with Pro Logic II Cinema matrix sur-
round, DD with Pro Logic II Music matrix
surround, or Dolby Digital 3 channel stereo.
You can also repeatedly press the 2CH
button on the front panel or the remote to
select the same options.
• On a 6.1/7.1 system. Press the SUR+
button on the remote, then use the +/– but-
tons to step through four optons: DD 2.0
channel, DD with Pro Logic IIx Cinema
matrix surround, DD with Pro Logic IIx
Music matrix surround, or Dolby Digital
3 channel stereo. You can also repeatedly
press the 2CH button on the front panel or
the remote to select the same options.
• To select Cinema or Music options in
Pro Logic II or Pro Logic IIx modes.
Press the SUR+ button twice while in Pro
Logic II or Pro Logic IIx modes. Then, use the
+/– buttons to select the Music or Cinema
options.
NOTE: When playing any Dolby Digital
source, you can select one of three dynam-
ic range control settings. See the Dynamic
Range topic in the Other Settings section of
this manual.
DTS 5.1 discs
DTS 96/24 discs
DTS-ES 6.1 discs
79
COP
DTS decoding is auto-detected and cannot
be overridden. You may, however, select a 2
channel downmix of 5.1 channel recordings
or add Rotel XS center back processing for
5.1 channel discs.
NOTE: In addition to the options that fol-
low, you can press the 2CH button on the
remote to toggle between 2-channel down-
mix and multichannel playback.
27
• On a 5.1 system. Press the SUR+ button
on the remote, then press the +/– buttons to
change between DTS 5.1 channel or DTS
2.0 channel downmix playback.
• On a 6.1/7.1 system with a DTS
5.1 disc. Press the SUR+ button on the
remote, then use the +/– buttons to step
through the optonal modes: DTS 2.0 chan-
nel downmix, DTS 5.1 channel, DTS with
Rotel XS center back processing, DTS with
Pro Logic IIx Music center back processing,
or DTS with Pro Logic IIx Cinema center
back processing (available only for 7.1
channel systems). Selecting DTS 5.1 forces
the center back channel processing off for
conventional 5.1 channel playback. You
can also repeatedly press the DTS Neo:6
button on the front panel until the desired
option is selected.
• On a 6.1/7.1 system with a DTS-ES
disc. Press the SUR+ button on the remote,
then use the +/– buttons to step through
three optional modes: DTS 2.0 channel
downmix, DTS 5.1, or DTS-ES 6.1ch/7.1ch
playback. On the front panel, press the DTS
Neo:6 button while playing a DTS source
to step through the same options.
• On a 6.1/7.1 system with a DTS
96/24 disc. Press the SUR+ button on
the remote, then use the +/– buttons to
step through the optonal modes: DTS 2.0
channel downmix, DTS 96, or DTS 96 with
Rotel XS center back processing. You can
also repeatedly press the DTS Neo:6 button
on the front panel until the desired option
is selected.

MPEG Multichannel discs

79
COP
MPEG decoding is auto-detected and cannot
be overridden. You may, however, select a
2 channel downmix of 5.1 channel record-
ings. If the system is configured with center
back speaker(s), you can also force Rotel XS
processing on or off.
NOTE: In addition to the options that fol-
low, you can press the 2CH button on the
remote to toggle between 2-channel down-
mix and multichannel playback.
• On a 5.1 system. Press the SUR+ button
on the remote, then press the +/– buttons
to change between MPEG 5.1 channel or
MPEG 2.0 channel downmix playback.
• On a 6.1/7.1 system. Press the SUR+
button on the remote, then use the +/– but-
tons to step through the optonal modes:
MPEG 2.0 channel downmix, MPEG 5.1
channel, MPEG with Rotel XS center back
processing, MPEG with Pro Logic IIx Music
center back processing, or MPEG with Pro
Logic IIx Cinema center back processing
(available only for 7.1 channel systems).
Selecting MPEG 5.1 forces the center back
channel processing off for conventional 5.1
channel playback. You can also repeatedly
press the DSP button on the front panel until
the desired option is selected.
Digital Stereo discs
(PCM, MP3, and HDCD)
7890
COP
This group of recordings includes any non-
Dolby Digital 2-channel signal from the
RSP-1068's digital inputs. You can play these
recordings in 2-CH Stereo, Dolby 3-Stereo,
5-CH Stereo, 7-CH Stereo modes. You can also
use Dolby Pro Logic II matrix surround (5.1 ch
systems), Dolby Pro Logic IIx Music (6.1/7.1 ch
systems), Dolby Pro Logic IIx Cinema (6.1/7.1
ch systems), DTS Neo:6 surround, or one of
the MUSIC 1-4 DSP modes.
All of the bass management settings (speaker
size, subwoofer, and crossover) are in effect
with digital stereo inputs.
NOTE: In addition to the options that fol-
low, you can select 2-channel, Pro Logic
II Cinema (for 5.1 ch systems), Pro Logic
II Music (for 5.1 ch systems), Pro Logic IIx
Music (for 6.1/7.1 ch systems), Pro Logic
IIx Cinema (for 7.1 ch systems), 5-channel
stereo, or 7-channel stereo by pressing
one of the surround mode buttons on the
remote (2CH, PLC, PLM, 5CH, 7CH).
• To select any mode for 2-channel
digital recordings. Press the SUR+ but-
ton on the remote, then use the +/– buttons
to step through the optonal modes until the
desired mode is displayed.
• To select STEREO mode for 2-chan-
nel digital recordings. Press the 2CH
button on the front panel or remote.
English
– continued
