RSP-1098 Surround Sound Processor
Selecting a Source from the
Remote
To select a source for LISTENING in the
main room: press and hold one of the DE-
VICE/INPUT buttons for more than one sec-
ond. To select the MULTI INPUT, press the EXT
button.
: A short press of a DEVICE/INPUT but-
NOTE
ton changes the remote control device only,
but does not change the source input.
To select a source for RECORDING: Press
the REC button and then press one of the DE-
VICE/INPUT buttons within 5 seconds.
Alternatively, you can press the REC button and
then use the +/– buttons to scroll through the
available source options. Select any input (CD,
TUNER, TAPE, or VIDEO 1–5). Selecting the
SOURCE option links the recording source to
the input selected for main room listening.
Whatever input is selected for listening is also
sent to the record outputs.
To select a source for Zone 2: Press the
ZONE button and then press one of the DE-
VICE/INPUT buttons within 5 seconds.
Alternatively, you can press the ZONE button
and then use the +/– buttons to scroll through
the available source options. Select any input
(CD, TUNER, TAPE, or VIDEO 1–5). Select-
ing the SOURCE option links the Zone 2 source
to the input selected for main room listening.
Whatever input is selected for the main room
is also sent to the Zone 2 outputs.
Overview of
Surround Formats
To get the best performance from your
RSP-1098, it helps to understand the many
surround sound formats available today, to
know which decoding process to use for a
particular recording, and how to select it. This
section provides basic background informa-
tion about surround sound formats. The follow-
ing sections provide detailed operating instruc-
tions for automatic and manual selection of
surround modes.
Dolby Surround
Dolby Pro Logic II
The most widely available surround sound
format for consumer audio/video is Dolby
Surround ® , available on nearly all commer-
cial VHS tapes, many television broadcasts,
and most DVDs. Dolby Surround is the con-
sumer version of the analog Dolby Stereo system
first introduced in the film industry in 1972. It
is a matrix-encoding system that records front
left, front center, front right, and a mono sur-
round channel into a 2-channel stereo record-
ing. During playback, a Dolby Pro Logic
Pro Logic II decoder extracts each channel and
distributes it to the appropriate speakers.
The original Dolby Pro Logic decoder deliv-
ered a mono signal with reduced high-fre-
quency content to the surround speakers. A
more advanced decoder in the RSP-1098,
Dolby Pro Logic II, increases the separation
and frequency response of the surround chan-
nels for significantly improved performance
with Dolby Surround encoded recordings.
Dolby Pro Logic II decoding should be used
for any analog recording labeled "Dolby Sur-
round" or any Dolby Digital 2.0 soundtrack.
Dolby Pro Logic II does a superb job deriving
surround sound from conventional 2-channel
stereo recordings, using phase relationships
to extract front, right, center, and surround chan-
nels. A "music mode" makes Pro Logic II an
excellent choice for audio CDs.

Dolby Digital

In 1992, an digital recording system, called
Dolby Digital, was first used in the film indus-
try. Dolby Digital is a recording/playback sys-
tem that uses compression techniques to store
large amounts of audio data efficiently, much
like the JPEG format stores large photographs
in small files on a computer. Because it is
capable of performance beyond that of au-
dio CDs and can tailor its output for a wide
ranges of system configurations, Dolby Digi-
tal is the standard audio format for DVDs and
for digital television broadcasting in the United
States.
The Dolby Digital system can be used to record
up to six discrete audio channels, but can also
be used for fewer. For example, a Dolby Digital
2.0 soundtrack is a digital 2-channel record-
ing of a matrix encoded Dolby Surround
soundtrack.. To play a Dolby Digital 2.0 re-
cording, use Dolby Pro Logic II decoding as
previously described.
24
The most common use of Dolby Digital in newer
films, in both the film industry and in home
theater, is Dolby Digital 5.1. Instead of encoding
multiple surround channels on a two-channel
recording, Dolby Digital 5.1 records six dis-
crete channels: front left, front center, front right,
surround left, surround right, and a Low Fre-
quency Effects (LFE) channel containing ultra-
low bass signals intended for a subwoofer.
A Dolby Digital decoder extracts the channels
from the digital bitstream, converts them to
analog signals and routes them to the appro-
priate amplifiers and speakers. All channels
® or
provide full frequency response with total sepa-
ration between all channels and large dynamic
range capability. A Dolby Digital 5.1
soundtrack can provide more impressive sur-
round sound than matrix Dolby Surround.
Decoding of Dolby Digital 5.1 soundtracks is
automatic. When the RSP-1098 detects a Dolby
5.1 signal on one of its digital inputs, it acti-
vates the proper processing. Keep in mind that
Dolby Digital is only available from digital
sources (a DVD, a LaserDisc, or a Digital TV/
Cable/SAT tuner). Also, you must connect the
source with a digital cable (coax or optical)
to an active digital input on the RSP-1098.
: Many DVDs have a Dolby Digital 2.0
NOTE
matrix soundtrack as the default, which should
be decoded with Pro Logic II. The Dolby Digi-
tal 5.1 soundtrack may have to be selected
as an option from the setup menus at the be-
ginning of the DVD. Look for a Dolby Digital
5.1 selection under "Audio" or "Languages"
or "Setup Options" when you insert the disc.

DTS 5.1

DTS 96/24

DTS ® (Digital Theater Systems) is an alterna-
tive digital format competing with Dolby Digital
in both movie theaters and home theater
markets. The basic functions of the DTS sys-
tem are similar to those of Dolby Digital (for
example, 5.1 discrete channels), however the
technical details of the compression and de-
coding processes differ somewhat and a DTS
decoder is required.
A recent extension of the DTS encoding sys-
tem is DTS 96/24. These recordings provide
the performance of a 96kHz sampling rate
while still using actual 48kHz sampling rate
of standard DTS discs.
