RSP-1068 Surround Sound Processor

Miscellaneous Settings

Other Options

����������������������
����������������������
��������������������
�������������������
��������������������
�����������������������
�����������������������
��������������������
������������������
������������������
�����������
This OTHER OPTIONS menu, accessed from
the MAIN menu, provides access to several
miscellaneous settings as follows:
RECORD: Select which source signal to be
sent to the recording outputs by choosing one
of the input sources. The options are: CD,
TAPE, TUNER, VIDEO 1–5, and SOURCE.
You can either select a specific component or
select SOURCE which will send the signal to
the record outputs from whatever source is
selected for listening.
TURN ON VOL: Specifies a default volume
level to be used each time the RSP-1068 is
activated. You can select LAST to have the
RSP-1068 power up with the last previously
used volume setting. Or, you specify a volume
from MIN (full mute) to MAX, in 1dB incre-
ments. Note that this setting cannot exceed
the MAX VOL established in the next line of
the menu.
MAX VOL: Specifies the maximum volume
level for the RSP-1068. The volume cannot be
adjusted above this level. Settings range from
MIN to MAX, in 1dB increments.
VOL SPEED: Provides three options for how
rapidly the volume control responds to inputs.
The SLOW setting adjusts the volume 1dB with
each control input. The MID setting adjusts in
2dB increments. The FAST setting adjusts in
3dB increments.
POWER: This setting determines how the
RSP-1068 powers up.
With the default STANDBY setting, the unit
powers up in standby mode when AC is
applied and the rear panel POWER button
is ON. The unit must be activated using the
front panel STANDBY button or the remote
ON/OFF buttons.
With the DIRECT setting, the unit is fully
activated when AC power is applied and the
rear panel POWER button is ON; however,
it may be put in standby mode using the
front panel STANDBY button or the remote
ON/OFF buttons.
In ALWAYS-ON mode, the unit remains fully
active whenever AC is present and the rear
panel POWER button is ON; the front panel
STANDBY button and the remote ON/OFF
buttons are disabled and the unit cannot be
put in standby mode.
LANGUAGE: Selects a language for the On
Screen Display.
VIDEO: Specifies whether an NTSC or PAL
television monitor is connected to the TV
MONITOR outputs of the RSP-1068. This set-
ting must be correct for the upconversion and
OSD menus to work properly.
OSD ON/OFF: Select whether or not status
information (such as the volume setting) is
displayed on the TV monitor.
PROGRESSIVE: The OSD menus cannot be
displayed on the TV monitor when progres-
sive scan or 1080i HDTV video signals are
being used at the Component Video inputs.
This setting enables a feature that allows the
display of the main OSD setup menus (but
not the information displays such as volume,
etc.) on the TV monitor by interrupting the
progressive scan video signal and restoring
it after the OSD menus are cancelled. Choose
the video input or combination of video inputs
for progressive scan or HDTV video signals
(480p, 720p, 1080i). All other video inputs
will be assigned as standard interlaced video
inputs. Video 4 and 5 cannot be assigned as
progressive scan inputs.
NOTE: When a video input or inputs
are selected for progressive mode, the
conversion from composite or S-Video to
Component Video output is not available
for those inputs. The conversion from com-
posite or S-VIDEO to Component Video
output is only available for the other video
inputs. For example, if Video 1 and Video
2 are selected for progressive scan signals
(V1+V2), conversion from composite or
S-Video is only available for Video 3, 4,
and 5.
Change settings on the OTHER OPTIONS
38
menu by highlighting the desired line using the
UP/DOWN buttons and using the +/– buttons
to step through the available settings. To return
to the MAIN menu, press the ENTER button.
Press the MENU/OSD button on the remote
to cancel the display and return to normal
operation.

Zone 2 Setup

��������������������
�����������
������������������
�����������������������
�����������������
�������������������
������������������
�������������������������
������
�����������
The ZONE 2 SETUP menu provides settings and
configuration options related to the operation
of Zone 2. This menu is reached by highlight-
ing the ZONE 2 line on the MAIN menu and
pressing ENTER.
SOURCE: Specifies a source for listening
in Zone 2. Options are CD, TUNER, TAPE,
VIDEO 1–5, SOURCE, and OFF. Selecting the
SOURCE option links the Zone 2 source to the
source selected for the main zone so that Zone
2 will hear the same source as the main zone.
Selecting the OFF option turns Zone 2 off.
VOLUME SETUP: configures the Zone 2
outputs for VARIABLE or FIXED volume levels.
VARIABLE allows control of the volume settings
in Zone 2 from the RSP-1068 front panel or
from a remote control/IR repeater in Zone
2. FIXED output disables the Zone 2 volume
control. In this mode, the Zone 2 level can be
fixed at the level specified on the next line, thus
optimizing system performance when sending
a fixed level signal to a preamp or amplifier
with its own volume adjustment.
VOLUME: In VARIABLE output mode, this
line shows the current volume setting for Zone
2. In FIXED output mode, this volume setting
establishes a permanent fixed output level
for Zone 2.
Move the highlight to the desired line using the
UP/DOWN buttons and use the +/– buttons
to adjust the volume level. To return to the
MAIN menu, press the ENTER button. Press the
MENU/OSD button on the remote to cancel the
display and return to normal operation.
