14 Hoofdafmetingen

Principal dimensions

Hauptabmessungen

Dimensions principales

Dimensiones principales
1 : 10
100 (3 15 / ")
16
vetus® Installation instructions thruster RIM DRIVE 250 mm
3
340 (13 / ")
8
1
184 (7 / ")
4
246 (9 11 / ")
16
L
76 (3")

Dimensioni principali

Mål
Huvudmått
Viktigste mål
Päämitat
88 (3 7 / ")
16
62 (2 7 / ")
16
340 (13 3 / ")
8
ø 250
(9 13 / " DIA.)
16
378 (14 7 / ")
8
150 (5 7 / ")
8
Made in Holland
Interface RimDrive Control
For 48 V DC RimDrive
RDIF
Model No.:
Serial No.:
1 2 3 4 5 6 7 8
Reset
Panel A Panel B Thruster Controller
020574.03
