Electric wire rope winch >BETA< SILVERLINE
English
Circuit diagram for el. wire rope winch with 1 wire rope speed for single-phase AC
Electric control with mounted-in reversing contactor, thermal motor protection, main switch, main contactor and electronic
overload protection (circuit diagram no. 4.1.431 - 0720(3))
If the connection between 24 V and PE will be disconnected, acc. to DIN EN 60204 an insulation monitoring is necessary.
Attention!
Brake must be con-
nected on DC side!
current fuses on site!
Fuse protection and connection have to be made acc. to local, national and international regulations!
Wiring diagram for el. wire rope winch with 1 wire rope speed for single-phase AC
technische Änderungen vorbehalten
main contactor
design changes under reserve
04.01.401
S0
S1
S2
S3
S4
S5
S6
F0
F1-F3
F2
F4
Q1
T1
K0
K1-K2
Up
Down
H1
Connection
network
The connecting plan integrated in
the motor terminal box has to be
observed.
Gleichrichter
rectifier
14 15
PE
changements techniques sous réserve
Emergency-Stop
Up
Down
upper limit switch (optional)
lower limit switch (optional)
slack rope switch (optional)
unlocking of electronic overload
protection
main current fuses have to be
provided on site (dimensions of
fuse, see page 19)
fuse (control voltage)
thermal motor protection
overload monitoring device
main switch
transformer
main contactor
reversing contactor lifting - lowering
signal lamp overload
to
single-phase
U1
U2 Z1 Z2
L
N
3
4
forward running
reverse running
Seite / page 24
