4. RESPONSIBILITY

The Manufacturer does not vouch for correctoperation of the panels or for any damage that they may
cause if they have been tampered with, modified and/or run outside the recommended work range or in
contrast with other indications given in this manual.

5. INSTALLATION

Strict observance of the power supply values shown in the electrical rating plate is required .
The electrical panel must be installed on a dry surface, in an atmosphere that is free from oxidizing or corrosive
gases, and where no vibrations occur. If installed outdoors, the units must be fully protected from direct
sunlight. Suitable measures must be taken to ensure that the ambient temperature is kept within t he operating
limits specified below. Moreover, the installation personnel must make sure that the cable glands are perfectly
sealed.
We recommend installing an earth leakage circuit breaker to protect the plant that is correctly sized,
type A, with the leakage current controlled of 100 mA and more,selective, protected against untimely shots.The
differential switch will automatically be marked by one of two symbols:
To the connection at the electrical panel provide a three-pole switch with opening contact distance of 3 mm and fuses
type gG (rapid) with current value appropriate to the group pumps to powered.
IT IS RECOMMENDED THE PROPER AND SAFE GROUND CONNECTION INSTALLATION!
MOTOR CABLE LENGTHS:
- L ≤ 10m:
NOT NEED ANY FERRITE
- 10m < L ≤ 50m:
WRAP 5 COILS OF THE THREE MOTOR CABLE (EXCLUDING GROUND) IN FERRITE SUPPRESSION XLM1
- L > 50m:
USE THE MOTOR REACTANCE XLL1

6. TECHNICAL DATA

Supply voltage.
Phases :
Frequency :
Modello:
Potenza nominale massima di impiego(kW):
Corrente nominale massima di impiego(A):
Dimensioni (LxHxP cm):
Peso (kg):
Grado di protezione:
Modello:
Potenza nominale massima di impiego(kW):
Corrente nominale massima di impiego(A):
Dimensioni (LxHxP cm):
Peso (kg):
Grado di protezione:
Modello:
Potenza nominale massima di impiego(kW):
Corrente nominale massima di impiego(A):
Dimensioni (LxHxP cm):
Peso (kg):
Grado di protezione:
ENGLISH
400V ±10%
3
50-60 Hz
2SP MFC 1,5T-2
2SP MFC 2,2T-2
3SP MFC 1,5T-2
3SP MFC 2,2T-2
2x1,5/3x1,5
2x2,2/3x2,2
2x3,7/3x3,7
2x5,3/3x5,3
2SP MFC: 40x50x20
2SP MFC: 40x50x20
3SP MFC: 60x80x25
3SP MFC: 60x80x25
28 - 33
28 - 33
IP55
IP44
2SP MFC7,5T-2
2SP MFC 11T-2
3SP MFC7,5T-2
3SP MFC 11T-2
2x7,5/3x7,5
2x11/3x11
2x15,5/3x15,5
2x23/3x23
2SP MFC: 60x60x25
2SP MFC: 60x80x30
3SP MFC: 60x80x25
3SP MFC: 80x80x30
28 - 33
60 - 75
IP44
IP44
2SP MFC 30T-2
3SP MFC 30T-2
2x30/3x30
2x61/3x61
2SP MFC: 80x170x40
3SP MFC: 100x200x40
(CABINET)
65 - 83
IP44
31
2SP MFC 3T-2
2SP MFC 4T-2
3SP MFC 3T-2
3SP MFC 4T-2
2x3/3x3
2x4/3x4
2x7,2/3x7,2
2x9/3x9
2SP MFC: 40x60x25
2SP MFC: 40x60x25
3SP MFC: 60x80x25
3SP MFC: 60x80x25
28 - 33
28 - 33
IP44
IP44
2SP MFC 15T-2
3SP MFC 18,5T-2
3SP MFC 15T-2
3SP MFC 18,5T-2
2x15/3x15
2x18,5/3x18,5
2x31/3x31
2x37/3x37
2SP MFC: 60x80x30
2SP MFC: 60x80x30
3SP MFC: 80x100x30
3SP MFC: 80x120x30
60 - 75
60 - 75
IP44
IP44
2SP MFC 5,5T-2
3SP MFC 5,5T-2
2x5,5/3x5,5
2x12/3x12
2SP MFC: 40x60x25
3SP MFC: 60x80x25
28 - 33
IP44
2SP MFC 22T-2
3SP MFC 22T-2
2x22/3x22
2x43/3x43
2SP MFC: 80x80x30
3SP MFC: 80x120x40
65 - 83
IP44
