During installation, attach the refrigerant piping securely before
running the compressor.
If the compressor is not attached and the stop valve is open
during pump-down, air will be sucked in when the compressor is
running, causing abnormal pressure in the freezer cycle which
will lead to breakage and even to injury.
Be sure to establish an earth. Do not earth the unit to a
utility pipe, surge absorber, or telephone earth.
Incomplete earth may cause electrical shock. A high
surge current from lightning or other sources may
cause damage to the outdoor unit.
Be sure to install an earth leakage circuit breaker.
Failure to do so may cause electrical shock.
Cautions
Do not install the outdoor unit in a place where there is
danger of exposure to inflammable gas leakage.
If the gas leaks and builds up around the unit, it may
catch fire.
Tighten the flare nut according to the specified method such as
with a torque wrench.
If the flare nut is tightened too hard, the flare nut may crack after
a long time and cause refrigerant leakage.
M
ODEL
RRHQ_V38 units include special equipment to ensure good
operation in areas where low ambient temperature can occur
together with high humidity conditions. In such conditions the
RRHQ_V3 models may experience problems with severe ice build up
on the aircooled coil. In case such conditions are expected, the
RRHQ_V38 must be installed instead. These models contain
countermeasures to prevent freeze up (insulation, a bottom plate
heater, ...).
A
CCESSORIES
Accessories supplied with the outdoor unit:
Installation manual
Fluorinated greenhouse gases label
Multilingual fluorinated greenhouse
gases label
Possible options
Bottom plate heater
RRHQ_V3 Optional kit
RRHQ_V38
(1) Combination of both options is prohibited.
RRHQ006~008ADV3(8)
Outdoor unit for air to water heat pump
4PW52843-1
1x
1x
1x
Drain socket
(1) (1)
Optional kit
Standard Use prohibited
I
NSTALLATION GUIDELINES

Precautions for selecting the location

WARNING
Make sure to provide for adequate measures in order
to prevent that the outdoor unit be used as a shelter
by small animals.
Small animals making contact with electrical parts can
cause malfunctions, smoke or fire. Please instruct the
customer to keep the area around the unit clean.
The equipment is not intended for use in a potentially explosive
atmosphere.
Choose a place solid enough to bear the weight and vibration of
the unit, where the operation noise will not be amplified.
Choose a location where the hot air discharged from the unit or
the operation noise will not cause a nuisance to the neighbours
of the user.
Avoid places near a bedroom and the like, so that the operation
noise will cause no trouble.
There must be sufficient space for carrying the unit into and out
of the site.
There must be sufficient space for air passage and no
obstructions around the air inlet and the air outlet.
The site must be free from the possibility of flammable gas
leakage in a nearby place.
Locate the unit so that the noise and the discharged hot air will
not annoy the neighbours.
Install units, power cords and inter-unit cables at least 3 m away
from television and radio sets. This is to prevent interference to
images and sounds.
Depending on radio wave
interference may still occur even if installed more than 3 m away.
In coastal areas or other places with salty atmosphere of sulfate
gas, corrosion may shorten the life of the outdoor unit.
Since drain flows out of the outdoor unit, do not place anything
under the unit which must be kept away from moisture.
NOTE Units cannot be installed hanging from ceiling or
stacked.

Selecting a location in cold climates

CAUTION
When operating the outdoor unit in a low outdoor ambient
temperature, be sure to follow the instructions described
below.
To prevent exposure to wind, install the outdoor unit with its
suction side facing the wall.
Never install the outdoor unit at a site where the suction side
may be exposed directly to wind.
To prevent exposure to wind, install a baffle plate on the air
discharge side of the outdoor unit.
conditions, electromagnetic
