Selva Narwhal 115 Manuel D'entretien page 488

BRKT
6 × 16 mm
8 × 40 mm
18 Nm (1.8 m • kgf, 13 ft • Ib)
Order
18 Power trim and tilt switch
19 Nut
20 Engine stop lanyard switch
21 Screw
22 Shift lever cover
23 Bolt
24 Shift lever
25 Bushing
26 Steering handle sub assembly
STEERING HANDLE (OPTION)
4 Nm (0.4 m • kgf, 2.9 ft • Ib)
5 × 20 mm
6 × 16 mm
Job/Part
6 × 40 mm
5 Nm (0.5 m • kgf, 3.7 ft • Ib)
Q'ty
1
1
1
2
1
1
1
1
1
For assembly, reverse the disassembly
procedure.
7-6
6 × 20 mm
6 × 25 mm
Remarks
E
7
7030
