CLAMP BRACKETS

REMOVING/INSTALLING THE CLAMP BRACKETS

Order
Upper case assembly
1
Grease nipple
2
Ground lead
3
Bolt
4
Ground lead
5
Anode bracket
6
Anode
7
Trim sensor
8
Self-locking nut
CLAMP BRACKETS
Job/Part
Q'ty
Refer to "UPPER CASE ASSEMBLY" on
page 7-16.
4
1
4
1
2
1
1
1
7-24
Remarks
Continued on next page.
