LOWR
SHIMMING (COUNTER ROTATION MODELS) (FOR WORLDWIDE)
B3
T3
A3 B4
59.0
SHIMMING (COUNTER ROTATION MODELS)
(FOR WORLDWIDE)
T1 B1 33.3 A2
A1 B2
15.1
NOTE:
• There is no need to select shims when
reassembling with the original case and
inner parts.
• Shim calculations are required when reas-
sembling with the original inner parts and
a new case (the difference between the
original inner parts and the new case).
• Measurements
required when replacing the inner part(s).
T2 T4
6-77
and adjustments
F
P
R
6A10
E
6
are
