3. Instructions for use

3.1 Selecting V-guides

Four sizes of V-guides are supplied
with the TKBA 40 to fit pulley grooves
of most widths and types. Should you
need to exchange the V-guides for
the smaller or larger one, select and
attach the appropriate V-guides as
shown in figure 2.

3.2 Attaching laser units

The units are provided with strong
magnets and V-guides. Place the
V-guides of the first unit in the
groove of the first pulley and press
the unit firmly until the magnet
secures it to the pulley.
Place the second unit in the opposite
groove of the second pulley.
Position both units facing each other
as shown in figure 4.

3.3 Power on

Switch on the laser unit by pressing the ON/OFF button.
SKF TKBA 40
Fig 2 Fitting or removal of V-guides
Fig 3 Mounting the unit
Fig 4 Units on pulleys
