13. Basic Settings of the Digital Trim

Before testing the control functions at the model, you must review the current position of the digital trimming or set it
correctly.
The remote control transmitter has four trimming buttons (also see figure 1, items 7 and 8), with the help of which the
middle position of the two control functions for elevator and rudder can be corrected.
When the model tends to fly to the left all the time later, for example, you may set the rudder with the rudder trimming
later so that the model flies straight again.
The trimming can be set during the flight.
Every short push on the trimming buttons makes the remote control issue a short signal sound that becomes higher or
lower depending on the trim direction of the button. If the trim button is held for longer, the sound is issued at a quick
sequence and quick adjustment will be performed.
When the centre position is reached, a double signal is issued. The end of the respective setting area is signalled with
a longer signal sound. The entire trimming path is approx. 30 single steps.
Put the trim settings to the middle position.
The rudder control for the rudder (1) and elevator (2) will take place by induction servos (3). If these control
motors are moved from their mechanical centre by trimming, this may cause humming at more or less of a
volume together with the fuselage as a resonance body. This is not an error, but a regular physical reaction
of induction servos.
42
Figure 6
