15. Checking the Control Functions

Before starting your model plane for the first time, you need to familiarise yourself with the control functions.
a) Motor Function
Attention!
Ensure that no loose parts, such as paper, film or other objects can be sucked into the rotor during this
motor test. Also make sure that the model is held securely during this test run and that no clothing and body
parts are within the rotation range or danger area of the rotor.
• Push the control lever for the motor function (figure 8) to the bottom position (motor off).
• First start up the transmitter and then the model plane (connect rechargeable battery).
• Push the control lever for the motor function slowly from the bottom to the top position (figure 9). The rotor will start
up and increase speed depending on control lever position.
• When the control lever is at the top stop, the maximum rotor speed is reached. Then move the control lever back
to the bottom-most position.
• Perform a brief motor test and check the run of the rotor.
• For the following tests of the elevator and rudder functions, observe that the motor is deactivated. Push the control
lever for the motor function (figure 8) to the bottom position (motor off).
Figure 8
Figure 9
