Short Leg 1x
Screw M6x12 4x
Attach the short leg to the top of the
grill firebox by use of 4 M6x12.
Make sure that rivet nut in the
shorter leg is facing to the top.
Long Leg 1x
Screw M6x12 4x
Attach the long leg to the bottom of
the grill firebox by use of 4 M6x12
screws.
Short Leg 1x
Screw M6x12 4x
Attach the short leg to the top of the
grill firebox by use of 4 M6x12.
Make sure that rivet nut in the
shorter leg is facing to the top.
