Key to figures:
Fig. 1
Overview of Wilo-RainSystem AF Comfort
1
Centrifugal pump
2
Base frame
3
Switchgear
4
Potable water replenishment reservoir
5
Connection for potable water supply
6
Pressure port connection
7
Pressure sensor
8
Suction port connection
9
Solenoid valve
10
Connecting piece for the replenishment reservoir
11
Overflow funnel
12
Level sensor
Fig. 2
Overview of switchgear
1
Display
2
Status indicator
3
"Go back" button
4
"Go forward" button
5
Confirmation (OK) button
6
Internal connections
7
Connection for pressure sensor
8
Connection for level sensor
9
Optional connection for reed relay
10
Enclosure screws
Fig. 3
Example installation with Wilo-RainSystem AF
Comfort
1
Collector tank
2
Level sensor
3
Suction line with foot valve
4
Filter collector
5
Wilo-RainSystem AF Comfort
6
Potable water connection
7
RainControl Economy (RCE) switchgear
8
Solenoid valve
9
Pressure sensor
10
Centrifugal pump
11
Overflow funnel
12
Pressure pipe supplying consumers
13
Auxiliary earth terminal
Fig. 4
Assignment of levels to the switchgear menus
Fig. 5
Level sensor connection
20
Fig. 6
Hydraulic connection diagram/dimension
drawing
1
Cover
2
Compartment for Installation and operating
instructions
3
Overflow
4
Mains connection (cable length approx. 2.5 m)
5
Level sensor (cable length approx. 20 m)
(within the scope of delivery! Installation
by customer/processor)
6
Auxiliary earthing screw
"
7
G1
Suction connection for rainwater storage
"
8
Rp 1
; Pressure port
"
9
R¾
; Potable water connection
10
Overflow funnel with HT70 connection (DN75)
Fig. 7
Filling centrifugal pump and suction line
Fig. 8
Drilling diagram for wall mounting
Free space needed for maintenance work
Fig. 9
Electrical connection diagram
