SSM/SBM relay forced control

13.4
Application and function of the di-
gital control inputs DI1 and DI2
Installation and operating instructions • Wilo-Stratos GIGA2.0-I, Wilo-Stratos GIGA2.0-D • Ed.02/2022-07
EBM The SBM function of the twin-head pump can be configured so that the SBM con-
tacts signal only operational messages of the respective pump (individual run signal). In
order to record run signals of both the pumps, both contacts must be assigned.
An SSM/SBM relay forced control is used as function test of the SSM/SBM relay and elec-
trical connections.
In the "Diagnostics and measured values" menu
1.
"Diagnostics help"
2.
"SSM relay forced control" or "SBM relay forced control" in sequence.
Selection options:
SSM/SBM relay
Forced control
Normal
Forced active
Forced inactive
Table 38: Selection option SSM/SBM relay forced control
The "Forced active" setting permanently activates the relay. A warning/operating note
(light) is permanently displayed/indicated.
The "Forced inactive" setting leaves the relay permanently without a signal. No warning/
operating note can be confirmed.
The pump can be controlled through external potential-free contacts at the digital inputs
DI1 and DI2. The pump can be
switched on or switched off,
controlled to maximum or minimum speed,
set manually into an operating mode,
protected against changes of settings through control or remote control or
switched between heating and cooling.
For a detailed description of the OFF, MAX, MIN and MANUAL functions, see "Settings menu
– Manual operation" [} 186] section.
In the "Settings" menu
, select
1.
"External interfaces"
2.
select "Function control input DI1" or "Function control input DI2".
Possible settings:
Selection option
Not used
External OFF
External MAX
External MIN
, select
Help text
SSM: Depending on the SSM configuration, fault and
warnings influence the SSM relay switching status.
SBM: Depending on the SBM configuration, the pump
status influences the SBM relay switching status.
SSM/SBM relay switching status is forced ACTIVE.
CAUTION:
SSM/SBM does not display the pump status!
SSM/SBM relay switching status is forced INACTIVE.
CAUTION:
SSM/SBM does not display the pump status!
Function control input DI1 or DI2
The control input does not have a function.
Contact open: Pump is switched off.
Contact closed: Pump is switched on.
Contact open: Pump is running in the mode set on
the pump.
Contact closed: Pump is running with maximum
speed.
Contact open: Pump is running in the mode set on
the pump.
Contact closed: Pump is running with minimum
speed.
en
195
