7.5.1

Select the setting code

Configuration settings for the pump:
1.
Keep the [MENU/EXIT]
operation.
ð The main menu for the pump is displayed and the Operating mode menu item
appears inverted.
2. Click the [down] button
ð The Configuration menu item appears inverted.
3.
By pressing the [START/STOP] button
confirmed
ð The screens switches to the Configuration menu.
4.
In the Configuration menu, click the [down]button
item.
ð The Code menu item appears inverted.
5. By pressing the [START/STOP] button
ð The inversion moves to the right. and the symbol - appears inverted.
6.
By clicking the [down] button
"Code query is active" ü or "Code query is inactive". -
ð If the code query has been set to "active", the following symbol appears on the
left: ü.
7. By pressing the [START/STOP] button
ð The setting is applied, and the display returns to the Configuration view
8. The Configuration level can now be exited again by pressing the [MENU/EXIT]
key combination.
ð The main menu for the pump is displayed and the Operating mode menu item
appears inverted.
9.
Press the [MENU/EXIT]
ð The display indicates the operating level (ongoing operation) of the pump
again.
You can find an illustrated description of this function in the User Manual for
the EMP II E60 diaphragm metering pump, Article No. 417101795
Ä Chapter 3 'Scope of supply' on page 20).
key combination pressed while the pump is currently in
to go to the Configuration menu item.
, the Configuration selection is
, the Code selection is confirmed.
or [up]button, the setting can now be configured for
, the ü selection is confirmed.
key combination again to exit the main menu.
39
Commissioning
to go to the Code menu
