12. Function menu

The EXR-46 OR's Function mode contains more advanced settings you may not need every day. They allow you to fine-tune your instrument's response. It would therefore be a good idea to familiarize yourself
with these parameters. Most settings ("*") can be written to a User Program (see p. 45). Other parameters ("°") are saved to the Flash memory when you leave the Function mode.
Editing parameters (general
procedure)
You can edit the EXR-46 OR's Function parameters via the dis-
play. Here is a general outline of the procedure for all parame-
ters discussed below:
(1) Press [FUNCTION].
FUNCTION
(2) Use FAMILY [√][®] to select the Function group that con-
tains the desired parameter:
FAMILY
I KB SET: KbdTouch, MsterTune, USRTrnsp, GLB Trnsp,
TransMod, PB Range, KeySplit, SpltHold, SpltInt, FSW, Port
Main, Port Dual, Mode Main, Mode Dual
I DRUM PAD: DK1/DrumPad1~DK8/DrumPad8
I METRONOM: Mtro TS, MetroVol, Count-In
I OCTAVE: MAIN Oct, DUAL Oct, SPLT Oct
I VOLUME: Main Vol, Dual Vol, SplitVol, Auto Bass,
AccDrums, AccBass, Accomp1~Accomp6, Song1~Song16
I ARR SET: ArrChord, Arr Hold, EP Chord, Bass Inv, MI (Mel-
ody Intelligence), InEnCHRD, Sync Stop
I EFFECTS: REV (Reverb), CHR (Chorus), MFX, Tone MFX, Rev
MAIN, Chr MAIN, Pan MAIN, Rev DUAL, Chr DUAL, Pan DUAL,
RevSPLIT, ChrSPLIT, PanSPLIT
I KB SCALE: Scale C/C#/D/Eb/E/F/F#/G/Ab/A/Bb/B, Scale
Mode
I MIDI: Local, MidiTxRx, Sync Rx, Style PC, LyricsTx,
NTARx14, PitchBnd, Modulatn, ProgChng, Velo Rx, Clock Tx,
StartStp, SongPosP
I UTILITY: LockInit, InitFLASH, Resume
I WriteSNG (see p. 49)
I WriteSTL (see p. 50)
I RemoveSNG (see p. 50)
I Remove STL (see p. 51)
I WriteUPG (see p. 50)
I ReadUPG (see p. 50)
I RemovUPG (see p. 51)
(3) Use SELECT [√][®] to select the parameter you wish to edit
(see below).
SELECT
Note: In FUNCTION mode, SELECT [√][®] do not allow you to
jump from one family to the next.
The "VALUE" message and a setting appear to signal that you
can change ("edit") the selected parameter.
(4) Use the DATA ENTRY [–][+] or numeric buttons (only for
values) to modify the setting of the selected parameter.
Note: See also page 20.
Note: To return to the default value of the currently selected
parameter, press [+] and [–] simultaneously.
(5) Use FAMILY [√][®] to select another Function parameter.
(6) Continue with step (3).
(7) Press another "big" button in the DATA ENTRY section to
leave this function.

KB SET parameters

I Kbd Touch*
(1~127, Default setting: 110) Use this parameter to set the
EXR-46 OR's fixed velocity value that will be used when the
icon is not displayed. See p. 34.
KEY TOUCH
Note: This parameter can also be selected by pressing and holding
[KEYBOARD¥TOUCH].
I MstrTune° (Master Tune)
(427.4~452.6, Default setting: 440.0) This parameter allows you
to change the EXR-46 OR's overall tuning, which may be nec-
essary when you accompany a singer, an acoustic instrument,
or when you play to a recording on CD or cassette.
I USRTrnsp*
(–12~12, Default setting: 0) Use this parameter to transpose
the EXR-46 OR in semitones. If you're not sure what transposi-
tion is, see p. 32. This parameter can also be selected by press-
ing the [TRANSPOSE] button.
I GLBTrnsp
(–6~5, Default setting: 0) Use this parameter to temporarily
transpose the EXR-46 OR in semitones. If you're not sure what
transposition is, see (see p. 33). This parameter can also be
selected by pressing the [TRANSPOSE] button and pressing
SELECT [®] once.
