The PosiTector Replica Tape Reader (RTR-3D) is a hand-held
electronic instrument that measures burnished Testex Press-O- Film
replica tape and uses a light intensity versus thickness algorithm to
produce three-dimensional (3D) images of the replicated surface.
Images generated within the gage are analyzed to produce 2D and 3D
parameters that represent specific characteristics of a surface.
Measurement
Peak Height H & Linearized Peak Height H
2D/3D Parameters*
2D/3D images (pg. 14)*
Save SDF surface data file (pg. 20)*
* Optical Grade Replica Tape is required for measuring 2D/3D parameters (pg. 5)
The PosiTector RTR-3D powers-up when the center navigation
button is pressed. To preserve battery life, the Gage powers
down after approximately 5 minutes of no activity. All settings are
retained.
With the Gage powered down...
1. Clean the probe with included cleaning card and microfiber
cloth. (pg. 9)
2. Power-up Gage by pressing the center
3. Zero the probe. (pg. 12)
4. Verify Gage accuracy. (pg. 10)
5. Measure the burnished replica tape. (pg. 8)
NOTE:
To ensure best accuracy, the user will be prompted to zero the probe
every time the Gage is powered-up. It is therefore good practice to clean the
probe regularly with the included cleaning card and microfiber cloth. Cleaning is
best performed when the Gage is powered down.
Tape Grade
Coarse (C)
X-Coarse (XC)
Optical Grade
Coarse (C)
Optical Grade
X-Coarse (XC)

Introduction

Quick Start

Tape Selection (pg. 5)
Height Measurement
L
2D/3D Parameters
2
RTR-3D
Advanced model only
Advanced model only
button.
