Display; Screen Capture - DeFelsko PosiTector RTR 3D Mode D'emploi

Print
Sends a statistical summary and individual measurements to the
optional Bluetooth wireless printer.
NOTE:
To cancel printing, press and hold the (-) and (+) buttons
simultaneously.

Display

The following user display options are available:
Chart: A real-time x-y chart of batch readings
Notes: Instructions, descriptions or notes (see Annotate,
pg.18)
None: Default screen shows statistics
SHORTCUT:
Batch Summary
Displays a summary of all stored
batches including the name, probe
type, number of readings and type.
In the following example, Batch 3
(B3) indicates an "RTR" replica
tape reader probe was used to
record a total of "41" readings.

Screen Capture

Press both (-)(+) buttons at any time to capture and save an image of
the current display. The last 10 screen captures are stored in memory
and can be accessed when connected to a computer (see PosiSoft
USB Drive pg. 26).
(appears only if a batch is currently open)
When a batch is open, press Up to scroll
through the above display options.
Advanced models only
19
