- Disconnect the two removable terminals from the monitor by pulling gently upwards. Do not pull the wires directly.
To reassemble the monitor:
[2]. Reconnect the connectors to the monitor.
[3]. Clip the front panel of the monitor to its rear section, sliding it to the right (ensure you position the thumb-wheels and
the adjustment selector correctly). Clip the monitor into place by gently pressing on the le -hand side.

3.2 Adding or removing the monitor RTS control with an exiting "3-button" receiver

[1]. Remove the monitor from its rear section (see 3.1 General information, page 5).
[1]. RTS monitor control: select the channel to be memorised
[2]. RTS transmitter already memorised: Press "PROG" for 2 seconds (see the RTS transmitter instructions)
- The LED on the RTS receiver lights up or the product moves briefly.
[3]. RTS monitor control: Briefly press "PROG":
- The LED on the RTS receiver flashes or the product moves briefly. the RTS control channel for the monitor is
memorised (or deleted if it was already memorised).
Begin the procedure again for all channels to be memorised or deleted.
[1] [2]
1..2..3..4..5
[4]. Return the monitor to its rear section (see 3.1 General information, page 5).
Note: To clear the programming on the video entry phone on a Somfy garage door motorisation, repeat all the steps detailed above.
