Rated current:
max. conductor
cross-section:
Protective earth
conductor cross-section:
Contact, foreign body and
ingress protection:
Application temperature
range:
Permissible ambient
temperature:
Labeling:
[1]
Ignition protection, ambient temperatures, temperature classifications and
[1]
IP ratings may vary. For applied marking see specific equipment label.

6. Commissioning of terminals

The following items have to be observed when commissioning the terminals:
- only EC model checked and approved terminals
- max. nominal cross-section
- max. current
- max. voltage
- The operating temperature range must be selected appropriately taking
self-heating into account.
During subsequent use of cross-connectors if necessary, the voltage must be
reduced. The instructions of the terminal manufacturer is to follow manda-
tory.
depending on fitted equipment and ambient
conditions
max. 240 mm², depending on fitted equipment
max. 120 mm², depending on fitted equipment
IP66 to EN/IEC 60529
IP65 to EN/IEC 60529 for polyester flange enclo-
sures
depending on fitted equipment,
maximum with
aluminium/stainless steel: -55°C to +135°C
polyester, polyester CombiBox: -55°C to +135°C
polyglas and polyester flange: -55°C to +100°C
according label
II 2 G Ex e d ia [ia] mb IIC T6, T5, T4 Gb
II 2 D Ex tb IIIC T85 °C, T100 °C, T135 °C Db IP66/IP65
0035
0035
