Tunturi Pure Cross R 2.1 Mode D'emploi page 64

45 Screw (#0816b)
46 User interface (SM2527-82)
47 Fix handbar end cap
48 Fix handlebar (LH)
49 Hand pulse sensor set w/o wire
50 Hand pulse wire (700mm)
51 PH self tapping screw (M4x5)
52 Allen head bolt (M8x15)
54 Pedal front end cap
55 Small spring
56 Wire rop
58 Upper swivel handlebar (LH)
59 Front stabilzer
60 Nylon nut (M8)
61 Flat washer (ø15.5x20x2.5t)
62 Billet (8x8x28l)
63 Flat washer (M8x16x1.2t)
65 Rear stabilizer
66 Nylon nut (M8)
67 Moving wheel
68 Carriage bolt (M8x60)
69 Height adjust foot
70 Allen head bolt (M8x20)
71 Hex head bolt (M8x52)
72 Fix handlebar (RH)
73 Fix handlebar foam grip
74 Side cover (LH)
75 Side cover (RH)
76 Screw (M6x15)
77 PH self tapping screw
78 Hex head bolt (M6x60)
79 Pulley (ø350)
80 Nylon nut (M6)
81 Magnet
82 Pulley shaft
83 Hex taper screw (M6x16)
84 Hex head bolt (M6x14)
85 Retaining ring C12
86 Flat washer (M6x16x1.2t)
87 Flat washer (M10x21x1.2t)
88 Rubber washer (M7xø22x2.5t)
89 Hex taper nut (M6)
90 Sensor wire (250mm)
91 Cover clip (M4)
64
4 92 Retaining ring C17
1 93 Bearing (6001zz)
2 94 Flywheel complete
1 95 Flywheel shaft
2 96 PH machine screw (M6x10)
2 97 Servo motor
2 98 Adaptor 6V DC/ 500ma
10 99 Drive belt (Poly-v 6pj1428)
2 100 Retaining ring C20
1 101 Bearing (6203zz)
1 102 PH machine screw (M5x12)
1 103 Large spring
1 104 Idle wheel bracket
1 105 Spacer sleeve
2 106 Wh nut (3/8"x26)
2 107 Dc wire (650mm)
16 108 Magnet shoe assembly
1
4
2
4
4
2
1
1
2
1
1
2
1
1
1
5
1
1
4
3
2
4
2
1
1
1
14
1
2
1
1
4
1
1
1
2
2
6
1
1
3
2
1
1
