Specifications

PRODUCT
Operating system ...Servo motor + PMS
Resistance levels ............................... 32
Flywheel weight ...............................6 kg
Rotating mass ................................33 kg
Power output @ 60 rpm ........ 220 Watt
Power output @100 rpm ......... 510 Watt
Power supply .................6V DC / 500mA
Height .........................................168 cm
Length .........................................150 cm
Width .............................................67cm
Weight ............................ 54 kg / 120 lbs
Max user weight ........... 135 kg / 300 lbs
MONITOR
Program display ................... 5,5"screen,
monochrome
Programs total ................................... 17
Pre-set programs ............................... 12
User programs ..................................... -
Watt program .............. 1 (10 - 350 Watt)
Hrc programs ....................................... 4
..................... (55% / 75% / 90% + target)
Recovery HR ........................................ 1
Max HR ................................................. 1
Quick start/ manual .............................. 1
Body fat + bmi ..................................... 1
User register ......................................... -
Fitness test ............................... Body fat
..........................................................BMI
................................................. Recovery
Control buttons ................................. Yes
ERGONOMICS
Stride length ..................... 16" ( ± 40cm)
Handlebar .................... Fixed, Multi Grip
Bottle holder ................................Option
HR chest belt .............. Option (5,4 kHz)
HR hand sensor ............................... Yes
Transport wheels .............................. Yes
QUALITY
Operating environment .................Home
En-957 class ..................................... HB
Owner's manual • Pure 2.1

Parts list

NO. DESCRIPTION
1 Base frame
2 Side cover metal strip
3 Crank arm (16")
4 Lower swivel handlebar (LH)
5 PH machine screw (M4x15)
6 Upper computer wire
7 Allen head bolt (M8x20)
8 Grub screw (M6x15)
9 Dc cover
10 Pedal post (RH)
11 Carriage bolt (M6x50)
12 Flat washer (M6x16xt1.2)
13 Pedal tube shaft
14 Flat washer (M8x18xt2.0)
15 Spring (M6)
16 Knob dawl
17 Rear pedal tube round cover
18 Allen head bolt (M8x25)
19 Spacer for turning shaft
20 Pedal post (LH)
21 Retaining ring (40x1.75)
22 Self-aligning bearing (2203)
23 Pedal washer
25 Pedal
26 Nylon nut (M6)
27 Lower computer wire
28 Screw (M10x30)
29 Lower swivel handlebar (RH)
30 Upper swivel handlebar (RH)
31 Sw handlebar foam grip
32 Handlebar end cap
33 Bearing (6002zz)
34 Screw (M8x25)
35 Metal plate for sw handlebar
36 Bearing (6004zz)
37 Sensor bracket
38 Wave washer (ø20xø27x0.4)
39 Plug axle support
40 Pivot shaft
41 Console bracket
42 Front post
43 PH machine screw (M5x12)
44 Spring (M8)
GB
QTY
1
1
2
1
14
1
10
2
1
1
4
4
2
2
4
4
2
2
2
1
2
2
4
2
2
1
2
1
1
2
2
4
2
2
6
1
2
2
1
1
1
4
14
63
