Technical Specifications - Stihl RM 3 RT Manuel D'utilisation

The measured and guaranteed sound
power levels were determined in
accordance with Directive 2000/14/EC,
Appendix VIII.
RM 3.0 RT
– Measured sound power level:
95.1 dB(A)
– Guaranteed sound power level: 96
dB(A)
RM 3.0 RTX
– Measured sound power level: 95 dB(A)
– Guaranteed sound power level: 96
dB(A)
The technical documents are stored in the
Product Approval department at STIHL
Tirol GmbH.
The year of manufacture and machine
number are indicated on the lawn mower.
Langkampfen, 02.11.2020
STIHL Tirol GmbH
p.p.
Matthias Fleischer, Head of Research and
Development Division
p.p.
Sven Zimmermann, Head of Quality
Division
0478 111 9938 A - EN

19. Technical specifications

RM 3.0 RT, RM 3.0 RTX:
Serial number 6361
Engine, design 4-stroke com-
bustion engine
Starter Rope start
Safety device Motorstop
Cutting tool Cutter bar
Cutting width 48 cm
Cutting tool drive Permanent
Cutting height 25 - 80 mm
Tightening torque for
blade fastening
screw 60 - 65 Nm
Self-propulsion, rear
wheels 1 forward gear
Wheel diameter
(front) 200 mm
Wheel diameter
(rear) 200 mm
Length 165 cm
Width 52 cm
Height 110 cm
RM 3.0 RT:
Engine: Manufac- Briggs & Stratton
turer, type Series 650 EXi
Displacement 163 ccm
Nominal output at 2,4 - 2800
nominal speed kW - rpm
Fuel tank 1,0 l
Cutter bar speed 2800 rpm
Weight 30 kg
Sound emissions
In accordance with Directive 2000/14/EC:
Guaranteed sound
power level L 96 dB(A)
WAd
In accordance with Directive 2006/42/EC:
Sound pressure level
at workplace L 82 dB(A)
pA
Uncertainty K 2 dB(A)
pA
Hand-arm vibrations
Specified vibration characteristic in
accordance with EN 12096:
Measured value a 4,80 m/sec²
hw
Uncertainty K 2,40 m/sec²
hw
Measurement in accordance with
EN 20643
RM 3.0 RTX:
Engine: Manufac- Briggs & Stratton
turer, type Series 550 EX
OHV RS
Displacement 140 ccm
Nominal output at 2,1 - 2800
nominal speed kW - rpm
Fuel tank 0,8 l
Cutter bar speed 2800 rpm
Weight 29 kg
Sound emissions
In accordance with Directive 2000/14/EC:
Guaranteed sound
power level L 96 dB(A)
WAd
In accordance with Directive 2006/42/EC:
Sound pressure level
at workplace L 82 dB(A)
pA
Uncertainty K 2 dB(A)
pA
Hand-arm vibrations
Specified vibration characteristic in
accordance with EN 12096:
Measured value a 5,00 m/sec²
hw
45
