English
Fault Cause
Lawn mower Blade is damaged.
vibrates
excessively.
Blade is not correctly attached.
Grass is not Blade is blunt or worn.
being cut
cleanly.

19 Specifications

19.1 STIHL RM 2.1 R, RM 2.0 RC
Lawn Mower
Engine type:
– RM 2.1 R: STIHL EVC 200
– RM 2.0 RC: KOHLER HD675
Displacement:
– RM 2.1 R: 139 cm³
– RM 2.0 RC: 149 cm³
Power:
– RM 2.1 R: 2.1 kW (2.8 HP) at 2800 rpm
– RM 2.0 RC: 2.2 kW (3.0 HP) at 2800 rpm
Speed:
– RM 2.1 R: 2800 rpm
– RM 2.0 RC: 2800 rpm
Maximum fuel tank capacity:
– RM 2.1 R: 0.9 l
– RM 2.0 RC: 1.4 l
Weight:
– RM 2.1 R: 24 kg
– RM 2.0 RC: 27 kg
Cutting width:
– RM 2.1 R: 46 cm
– RM 2.0 RC: 46 cm
19.2 Blade
– Minimum thickness a: 2.0 mm
– Minimum width b: 45 mm
– Sharpening angle c: 30°
30
Remedy
Replace blade.
Attach blade.
Sharpen or replace blade.
19.3 Sound Values and Vibration
Values
RM 2.1 R
The K value for the sound pressure level is
2 dB(A). The K value for the sound power level is
1.4 dB(A). The K value for the vibration values is
3.16 m/s².
– Sound pressure level L
ance with 2006/42/EC: 79 dB(A)
– Sound power level L
ance with 2000/14/EC: 91 dB(A)
– Vibration value a
with EN 12096, handlebar: 7.90 m/s²
RM 2.0 RC
The K value for the sound pressure level is
2 dB(A). The K value for the sound power level is
2.1 dB(A). The K value for the vibration values is
2.20 m/s².
– Sound pressure level L
ance with 2006/42/EC: 79 dB(A)
– Sound power level L
ance with 2000/14/EC: 91.3 dB(A)
– Vibration value a
with EN 12096, handlebar: 4.40 m/s²
For information on compliance with Employers'
Vibration Directive 2002/44/EC, see
www.stihl.com/vib.
19.4 REACH
REACH is an EC regulation and stands for the
Registration, Evaluation, Authorisation and
Restriction of Chemical substances.
For information on compliance with the REACH
regulation see www.stihl.com/reach.
20 Spare Parts and Accesso‐
ries
20.1

Spare parts and accessories

These symbols indicate original STIHL
spare parts and original STIHL acces‐
sories.
19 Specifications
measured in accord‐
pA
measured in accord‐
wA
measured in accordance
hv
measured in accord‐
pA
measured in accord‐
wA
measured in accordance
hv
0478-111-9949-B
