7. Reassemble in reverse order. Place the washer into the nylon stem as shown in Figure m. Apply a drop of
locking fluid to the tip of the thread near the end of the screw. Push the screw up though the end of the stem
and through the washer.
8. Finally, slip the spring/plunger on the handle down into the stem. Rotate the stem until the slot in the stem
aligns with the rib in the handle and slips all the way into the handle, then tighten the screw.
9. Wait 24 hours before using the device to ensure that the locking resin obtains full strength. During this time,
the ResQPUMP should be hung by the strap or left resting on the handle with the suction cup pointing up.
7.

TECHNICAL SPECIFICATIONS

Operating Specifications
Force gauge compression range
Force gauge decompression range
Metronome Function
Signal pitches
Sound level
Rate
Temperature Range
Operation
Storage
Dimensions
Suction cup
Height
Weight
Materials
Suction cup and cushion pad
Handle and support ring
Connection stem
Support ring
Metal parts
Battery
Battery life:
Battery shelf life:
8. ACCESSORIES AND REPLACEMENT COMPONENTS AVAILABLE
Reorder # Description
12-0586-000 Suction Cup for ACD-CPR Device (replacement suction cup with support ring and
compression cushion)
12-0935-000 ResQCPR Carrying Case (holds one ResQPUMP and two ResQPODs)
12-2116-000 ManiKIT (permits many CPR manikins to be adapted for ACD-CPR)
4
English
0 - 50 kg ± 15%
0 - 15 kg ± 15%
768 Hz (low) and 3070 Hz (high)
≥65 dB at distance of 0.5 m for sound source
80 per minute
-18º to 50º C (0º to 122º F)
-40º to 60º C (-40º to 140º F)
13.5 cm OD
17.0 cm
0.58 kg
Silicone
Polyamide (nylon), glass fiber reinforced
Acetal polyoxymethylene
Thermoplastic polyester elastomer
Stainless steel and brass
3.6 V primary lithium-thionyl chloride
Minimum of 20 service hours
Approximately 10 years
