RDV-1092 RDV-1092 DVD Audio/Video Player

SETUP

The RDV-1092 has a comprehensive On-
Screen Menu system that provides access to
operating features and user-configured prefer-
ences. These include language preferences,
video display options, hardware configura-
tion settings, and speaker settings to match
the unit to your system.

On-Screen Menus

This section provides general instructions for
using the On-Screen Menus to configure the
RDV-1092.
1. Press the SETUP button on the remote. The
Top Level Menu appears on the TV moni-
tor. This menu provides access to seven
categories of settings and features:
MENU
DVD playback
system setup
video setup
audio setup
speaker setup
parental control
high def. setup
exit menu
2. Press the CURSOR buttons to highlight
the desired item and press the ENTER but-
ton or the CURSOR button to display
the corresponding pop-up Options Menu.
In this example, the options for the DVD
playback selection are shown:
MENU
DVD playback

audio track

system setup

camera angle

video setup

subtitle

audio setup

DVD auto play

speaker setup

subtitle pref.

parental control

audio lang. pref.

high def. setup audio fmt. pref.
exit menu
3. Press the CURSOR buttons to highlight
the desired option and press the ENTER
button or the CURSOR button to display
the pop-up Settings Menu showing the
choices for that option. In this example,
the options for the audio track selection
are shown:
4. Press the CURSOR buttons to select
the desired setting from the pop-up win-
dow. In this example, you can select the
Dolby Digital 2.0 or Dolby Digital 5.1
audio tracks.
5. Press the ENTER button to confirm the new
setting.
6. Use the CURSOR
navigate the menus and make additional
settings.
7. After several minutes, the menus auto-
matically disappear. Or, press the SETUP
button again to exit the menu system and
return to normal operation.
: Context-sensitive help instructions ap-
NOTE
pear on the Settings menu or after pressing
the MENU button.
The following sections describe the settings
available from each of the seven items on
the Top Level Menu.

DVD Playback Menu

MENU
DVD playback audio track
system setup camera angle
video setup subtitle
audio setup DVD auto play
speaker setup subtitle pref.
parental control audio lang. pref.
high def. setup audio fmt. pref.
exit menu
There are seven items on the DVD playback
options menu when a disc is inserted in the
RDV-1092. If a disc is not inserted the four
options under the DVD auto play item are
shown automatically.
The following details each of the seven
menu items.
Audio Track
Select an audio track for the currently played
DVD. The available options depend on the
specific disc and may typically include Ste-
reo, Dolby Digital 2.0, Dolby Digital 5.1,
DTS 5.1, plus soundtracks recorded in various
languages. This selection overrides the default
setting, but only for the current disc.
: This selection can also be made from
NOTE
the DVD's own start-up menu or by pressing
the AUDIO button on the remote.
Camera Angle
Some DVD-Video discs include optional
camera angles for particular scenes. When
these optional camera angles are available,
this setting allows you to select your prefer-
ence. When a disc or scene has no optional
camera angles, "1 of 1" will display on the
Setting Menu.
24 24
buttons to : This selection can also be made from
NOTE
the DVD's own start-up menu or by pressing
the ANGLE button on the remote. If no op-
tional camera angles are available, the Sta-
tus Bar does not appear when the ANGLE
button is pressed.
Subtitle
Select a language as the subtitle language
for the currently playing DVD when it is avail-
able on the disc. You can also select OFF so
that DVDs are played without subtitles. This
selection overrides the default setting, but
only for the current disc.
: This selection can also be made from
NOTE
the DVD's own start-up menu or by pressing
the SUBTITLE button on the remote.
DVD auto play
This selection specifies whether DVDs begin
playing automatically when they are inserted
into the RDV-1092:
• ON: (default) Discs will begin playing
automatically.
• OFF: Discs will not begin playing auto-
matically. "Loading" appears in the front
panel display. Press PLAY
button to start playback.
Subtitle Pref.
Select a language as the default subtitle lan-
guage for DVDs when that language is avail-
able on the disc. You can also select OFF so
that DVDs are played without subtitles as the
default. You can override the default setting
and select a different language when playing
a specific disc. When a disc does not have
menus in the selected language, the menus are
displayed in the disc's default language.
Options include:
• English (default)
• Francais
• Spanish
• Deutsch
• Italiano
Audio Lang. Pref.
Select a language as the default audio lan-
guage for DVD sound tracks when it is avail-
able on the disc. You can still override the
preference and select a different language
or the ENT
