Remote Control Overview

See Figure 2
The RDV-1092 is supplied with an RR-DV98
remote control that duplicates the front-panel
functions and provides additional features.

Remote Control Batteries

Three R03(LR03)/AAA size batteries (sup-
plied) must be installed before the remote can
be used. Remove the cover on the back of the
RR-DV98. Install the batteries following the
polarity symbols, then replace the cover.
: Remove the batteries from the remote if
NOTE
it will not be used for a long period of time.
Do not leave run down batteries in the remote
control; they can leak corrosive chemicals
which will damage the unit.

Using the Remote

To use the remote, aim it at the remote sensor
on the front-panel of the RDV-1092. The op-
eration of the remote sensor can be affected
if it is blocked or exposed to bright infrared
light. In addition, remote control functions
may not work reliably if the batteries in the
RR-DV98 are weak.

ON/OFF Buttons

These two buttons provide discrete ON/OFF
functions. Press the ON button to activate the
RDV-1092 and the OFF button to put the unit
in standby mode.
: The front panel master power button
NOTE
must be pressed in for the remote ON/OFF
buttons to work.

OPN/CLOSE Button

Pressing this button opens or closes the Disc
Drawer. If in standby mode, pressing the but-
ton activates the unit.

PLAY Button

The PLAY button duplicates the function of
the front panel PLAY button and is used to
confirm selections in menus. Press this button
to start playing the disc from the beginning
or to resume play if playback is paused or
to return to normal play from any of the slow
motion or fast play modes. If in standby mode,
pressing the button activates the unit.
17 17

STOP Button

Press the STOP button to stop a disc that
is playing. If playback is restarted after one
press of the button, the disc will resume play-
ing from the current position on the disc. Press
the button twice to cancel the resume feature.
Subsequent play will restart from the beginning
of the disc. Playback will also stop when the
OFF button on the remote is pressed.

PAUSE Button

Press the PAUSE button to temporarily sus-
pend play or to advance the still picture frame
by frame after playback is paused.

TRACK Buttons

The TRACK buttons skip forward/
back to the beginning of the next selection.

SEARCH Buttons

During playback, press the SEARCH
buttons to begin high-speed play, either for-
ward or reverse, at 2X, 4X, 8X, 16X, 30X,
or 60X normal speed, increasing with each
additional press. Press the PLAY
resume normal speed playback.

Numeric Buttons

These buttons (1–0 and +10) are used for
direct entry of specific Chapters, Titles, and
times. Two digit numbers are typically entered
by pressing +10 followed by the next digit,
as detailed in operating steps.

CURSOR Buttons

Use the four CURSOR
navigate the on-screen display menus.
The left/right CURSOR
used for Program play mode (CD only).

ENTER Button

This button (labeled ENT) is used to confirm
many selections in operating the RDV-1092.
We refer to this button as the ENTER button
throughout this manual.

MENU Button

Press the MENU button to activate the menu
on the disc.
The MENU button is also used the clear the
Program play menu (CD only).

SETUP Button

Press this button to access the Main Menu
screen used in the setup of the RDV-1092.

DISPLAY Button

The DISPLAY button changes the time shown
in the front panel display and shows a time
display in the Status Bar display. Several op-
tions are available including elapsed time and
remaining time of individual Chapters/Tracks
or entire Disc/Titles.

TITLE Button

Press the TITLE button to activate the submenu
for the current Title. On some discs, this but-
ton will activate the same root menu as the
MENU button.

SLOW Button

Press this button to select slow motion play,
either forward or reverse, at 1/2, 1/4, or
1/8 normal speed.
The SLOW button is also used to view still
pictures on a DVD-Audio disc. Each press of
button to
the button advances to the next picture.

GOTO Button

Press the GOTO button for direct selection of
a particular Time, Title, or Chapter with the
NUMERIC buttons. The first press of the GOTO
button allows direct entry of Time. Press the
GOTO button a second time for direct entry
of a Title number. A third press allows direct
entry of a Chapter.
For example, to select Chapter 5, press the
buttons to
GOTO button three times to reach the Chap-
ter entry mode. Then press 0 followed by
buttons are also 5. Press the PLAY
playback at the selected point.

ANGLE Button

Press the ANGLE button to select an alter-
nate angle view (if available for the current
scene).
: "Operation not possible" displayed in
NOTE
the status bar indicates that this feature is not
available for the current scene.
English
or ENT button to begin
