Commissioning

10
9
8
7
6
5
4
3
2
1
-50 -40 -30 -20 -10
Fig. 2
18
4 Commissioning
The pressure-temperature diagram (P-T diagram) specifies the
material resistance of the various versions of the backpressure
valves (for water).
CAUTION
The pressure and temperature of the metered medium must be
below the corresponding curve!
Otherwise the backpressure valves may fail prematurely!
PC1
PP1
0 10 20 30 40
temperature in °C
CAUTION
• System components may burst if the setting pressure is
adjusted too high!
• The setting pressure P
always be lower than the maximum permissible operating
pressure P of pulsation dampers, pumps and line systems.
N
PV1, TT1, SS1
50 60 70 80 90 100 110
at the backpressure valve must
E
