Spare Parts / Dimensional Drawing
Version Pos. Description
SS 1
5 Formed diaphragm
8 Compression spring
15 Envelope ring
for piston
22 Envelope ring
26
10 15
1000309
1000312
1000321
483983 483984 483985 483986 1000308 483987
11

Dimensional Drawing

H
h
m
D
L
DN G L approx. H approx.
10 G 3/4 120
15 G 1 120
20 G 1 1/4 150
25 G 1 1/2 150
32 G 2 205
40 G2 1/4 205
* = PP, PVC, PVDF, ** = TT, SS
Nominal width DN
20 25 32
1000310 1000311
1000313 1000314
1000322 1000323
DN
G
Fig. 9
h* h**
175 25 20
175 25 20
202 38 25
202 38 25
260 59 37
260 59 37
40
D m
81 M6
81 M6
107 M6
107 M6
147 M8
147 M8
