10.3.4 Pause
The pause function can be used, for example, to replace the filament.
⇒ Press the
en
♦ The icon changes to
♦ Printing is interrupted
♦ The print head is moved to the left edge so that the object is not damaged
when a new filament is inserted.
If you would like to replace the filament, use the
unload / load the filament and proceed as described in Chap. 7.6 / 7.4.
Resuming printing:
⇒ Press the
♦ The print head moves back to the object
♦ Printing is resumed�
10.4 Printing with SIMPLEX print
If the SIMPLEX 3D-filament-printer is connected directly to a computer using the USB cable, objects can
be printed with SIMPLEX sliceware using SIMPLEX print.
The print process using SIMPLEX print cannot be followed on the display of the SIMPLEX 3D-fila-
ment-printer.
For this reason, the alternative is available of printing using a USB flash drive. (Chap 10.2 / 10.3).
If printing is carried out using the SIMPLEX print program, printing is controlled
exclusively via SIMPLEX print.
Only the main menu is shown on the SIMPLEX 3D filament printer.
Actions should not be performed via the display�
The options described in the previous chapter (10.3) are only available with
SIMPLEX print.
10.4.1 Connecting the printer via USB cable
⇒ Connect the USB cable to the USB outlet of the SIMPLEX.
⇒ Connect the cable to a USB port on your computer�
⇒ Switch on the printer�
10.4.2 Automatically starting SIMPLEX print
When you click the "Print" command in SIMPLEX sliceware, SIMPLEX print is automatically started.
3
⇒ Close the error message with "OK".
⇒ Click "Printers" and "Detect SIMPLEX 3D printers" to activate the connected SIMPLEX 3D-filament-
printer (alternatively, press CTRL+R).
♦ The SIMPLEX is shown in the status bar (1, Fig. 67)
⇒ Select and load the G-Code by clicking the load button (3, Fig. 67).
♦ The corresponding file name is shown in the status bar (2, Fig. 67)
button (see Fig. 59).
�
icon�
1
2
/ or / buttons to
- 28 -
Fig. 64
Fig. 65
Fig. 66
Fig. 67
