USING THE RANGE
FEATURES OF THE OVEN
NOTE: Not all features are on all models.
49-2001169 Rev. 2
1
Full Extension Oven Rack
3
Temperature Probe
5
6
7
8
9
Feature Index
1 Full Extension Oven Rack(s)
2 Broiler Pan and Grid - 1 large in oven (Right oven
on 48" models), 1 small in left oven
3 Temperature Probe - 1 per oven
4 Roasting Rack
5 Broil System
6 Halogen Oven Columns
7 Oven Rack Supports
8
9 Oven Door Seal
10 Oven Frame Seal
11 Temperature Probe Outlet
12 Convection Fan
13 Soft-Close Oven Door
14 Automatic Oven Door Latch
2
Broiler Pan and Grid
4
Roasting Rack
14
12
10
11
13
