RIB R50 Mode D'emploi page 24

G
B
SYSTEM LAY-OUT
2
5
4
5
1 - R50 operator
2 - Radio antenna
3 - Blinker
4 - Photoelectric cells (external)
5 - Photoelectric cells (internal)
6 - Key selector
T
Gearmotor for operating industrial swing gates with overall
maximum weight of 2000 kg.
The R50 is an irreversible electric gearmotor with adjustable
drive force, regulated by changing the pressure exerted by the
3
drive wheels on the ground.
The drive wheels are able to run over surface irregularities of
up to 6 cm (approx.), because the gearmotor unit slides along
a vertical track. The pressure setting between the drive wheels
6
and the ground can vary from 30 to 130 kg maximum and is
maintained by an adjustable spring.
5
TECHNICAL DATA
Max. leaf length
Max. leaf weight
Average opening time 90°
1
Operating speed
6
EEC Power supply
4
Motor capacity
Power absorbed
Capacitor
1
EEC Power supply
Motor capacity
Power absorbed
5
Capacitor
230/50-60 Normative cycles
120/60 Normative cycles
Daily cycles suggested
Service
Consecutive cycles guaranteed
Grease
Actuator weight
Operating temperature
1
Protection grade
Measurements in mm
24
24
ECHNICAL FEATURES
m
kg
s.
m/s. 0,180 (50Hz) - 0,216 (60Hz)
230V~
W
A
mF
W
A
mF
n°
n°
n°
n°
COMLUBE LHITGREASE EP/GR.2
kg
°C
IP
R50
10
2000
78
50Hz 60Hz
437 511
1,96 2,32
16
120V~ 60Hz
251
2,26
40
3 - 78s/2s
8 - 78s/2s
300
60%
4/78s
45
-10 ÷ +55°C
54
2
