10.2

Understanding the "Recording" Sub-menu

"Welder Code on" means that the welder identification code
to be entered as set with "Welder Code Options," "off," that this is
impossible.
"Commission Number on" means that the commission number
(job number) will have to be entered or confirmed before every
new welding, "off" that the user is not prompted to enter it.
"Print Tags – M – " means that by pressing the MENU key, the
user can access a sub-menu for starting to print (a) label(s) with
reference to a given welding operation, with the optional label tag
printer.
All data can also be read from a bar code with the scanner, provided such a bar
code is available.
11

Self-Monitoring Functions Overview

11.1

Errors During Data Input

• Code Error
An erroneous input has occurred, a code tag is poor or has an error in code symbology or
code reading was improper.
• No Contact
There is no properly established electric contact between the welding unit and the fitting
(check push-on terminal on fitting), or the heater coil is defective.
• Low Voltage
The input voltage is below 175 volts. Adjust generator output voltage.
• Overvoltage
The input voltage is over 290 volts. Decrease generator output voltage.
• Overheated
The transformer temperature is too hot. Let the welding unit cool down for about 1 hour.
• System Error
CAUTION! The welding unit has to be disconnected immediately from both the
power supply and the fitting. The auto-test has detected an error in the system. The
unit must no longer be operated and has to be sent to an approved shop for check
and repair.
• Temperature Error
The ambient temperature measured is outside the operating range of the welding unit, i.e.,
below – 20°C (– 4°F) or over + 60°C (+ 140°F).
• Temperature Sensor Defective
The ambient temperature sensor on the welding cable is damaged or defective.
• Clock Error
The internal system clock works improperly or is defective. Reset it, or send the welding unit to
the manufacturer for check and service.
• Unit to Service
The recommended next service date for the welding unit is overdue. The service due message
has to be acknowledged by pressing the START/SET key. Send the welding unit to the
manufacturer or an approved service point for service and check-up.
• Input Error
A code that was entered is incorrect. At manual welding parameter input, no welding time was
entered. An incorrect value was selected in the date setting.
• Memory Full
The system memory is full of welding reports. Print or download the reports in memory or
ENGLISH
has
Data Recording
Welder Code
>Commission No.
Print Tags
on
on
– M –
Display 19
