Memory Control on" means that when the system memory is full
of reports, the unit will be blocked until the reports are printed
or downloaded, "off," that it works but that the oldest report will
be overwritten.
"Manual Input on" means that the manual input of welding
parameters (see Sect. 7) is possible, "off," that the manual
input is not allowed.
"Welder Code Options – M – " means that by pressing the MENU
key, the user can access a sub-menu that allows determining
when the welder code,
be entered:always, i. e. before evey single welding operation,
only before the first welding operation after switching the unit
on or only after the first welding operation of a new day/date.
"Language – M – " means that by pressing the MENU key, the
user can access a sub-menu for selecting the display and
report language (see Sect. 10.1.1).
"Date/Time – M – " means that by pressing the MENU key,
user can access a sub-menu for setting the clock (see
Sect. 10.1.2).
"Buzzer Volume – M – " means that by pressing the MENU key,
the user can access a sub-menu for setting the volume of the
status buzzer (see Sect. 10.1.3).
"Temperature Unit – M – " means that by pressing the MENU key,
the user can access a sub-menu for selecting centigrade or
Fahrenheit as the unit for the temperature.
"Number of Tags – M – " means that by pressing the MENU key,
the user can access a sub-menu for entering the number
of tags that are printed automatically after welding with the
optional label tag printer if such a printer is connected.
10.1.1 Selecting the Display Language
When the "Select Language" sub-menu was selected, the screen
changes and the display reproduced in Display 16 appears
Use the arrow keys ñ and ò to select one of the options,
"Deutsch," "English," and "Français" and confirmby pressing the
START/SET key.
10.1.2 Setting the Clock
When the "Set Clock" sub-menu was selected, the screen
changes
and the display reproduced in Display 17 appears.
The time of day and the date can be set using the keypad. The
portions "Hour," "Minute," "Day," "Month," and "Year" are set
separately. Press the START/SET key to confirm your settings.
10.1.3 Setting the Buzzer Volume
When the "Set Volume" sub-menu was selected, the screen
changes
and the display reproduced in Display 18 appears. The
buzzer can also be heard. Turn the buzzer volume up or down to
the desired value using the ï, ð arrow keys (from 0 to 100) and
confirm your setting by pressing the START/SET key.
10.1.4 Selecting the Temperature Unit
The unit of temperature values (Centigrade or Fahrenheit) can be selected in a sub-menu
similar to the language selection (see Sect. 10.1.1).
26
if it is enabled at "Recording," has to
ENGLISH
***
SET-UP MENU ***
Wldr Code Option-M-
>Language
Date/Time
the
***
SET-UP MENU ***
Buzzer Volume
>Temp. Unit
Number of Tags
***** LANGUAGE *****
.
>Deutsch
English
Francais
Date/Time
21.06.13
Buzzer Volume
< ------20-------- >
-M-
-M-
Display 14
-M-
-M-
– M –
Display 15
Display 16
14:28
Display 17
Display 18
