Failure to comply with this provision will dispense the manufacturer from any
warranty and liability claims for the product, including any consequential damage.
When serviced, the unit is upgraded automatically to the technical specifications of the product
at the moment it is serviced, and we grant a three-month functional warranty on the serviced
unit.
We recommend having the product serviced at least every twelve months.
In Germany,we recommend using ROTHENBERGER-Service.
3.2

Transport, Storage, Shipment

The product ships in a transport box. The product should be stored in this box, protects the
product from humidity and environmental agents.
When sending the product, it should be placed into the transport box at all times.
4

Principles of Operation

The ROWELD ROFUSE Basic 48 V2.0 allows welding electrofusion fittings that feature a
bar code. Every fitting is provided with a tag with one or two bar codes on it. The structure of
this code is internationally standardized. The first code, encoding the data on proper welding,
complies with ISO 13950, the second code, if present, encodes component traceability data,
some of which are managed by the welding unit.
The welding parameters can also be entered manually. The microprocessor-controlled
ROWELD ROFUSE Basic 48 V2.0 Welding Unit
• controls and monitors the welding process in a fully automated fashion,
• determines welding duration depending on ambient temperature,
• shows all information on the display in plain text.
All data that are relevant for the weld or for traceability are saved to the internal memory and
can be sent to a USB stick.
Welding data transfer is enabled through an interface of the USB A type, which is compatible
with a USB stick.
Further Optional Accessories
• PC software for downloading and archiving data on PC (for all common Windows operating
systems)
• USB stick for data transfer from the welding unit on the worksite to the printer or PC in your
office (see details at the end of this booklet)
5

Check-out and Operation

 To operate the welding unit, be sure that it is set on a proper, level surface.
 Be sure that power supply/generator protection is 16 A (slow blow).
 Plug the power supply cord into the mains power supply or the generator.
 Read and comply with the User's Manual of the generator, if applicable.
5.1

Turning the Welding Unit On

After connecting the power supply cable to mains power or a
generator, turn the welding unit on using the On/Off switch. This
causes Display 1 to show
Then the screen changes to Display 2.
CAUTION in case of System Errors! If during the auto-test that the unit performs
at start-up, an error is detected, a "System Error" message shows on the
display. When this happens, the welding unit has to be disconnected
immediately from the power suppy and the fitting, and it has to be shipped to
the manufacturer for repair.
20
.
ENGLISH
Roweld
Welder
ROFUSE BASIC 48
Version 2.0
Display 1
