2.7

Checking the Product for Damage

Before every use of the product, check safety features and possibly existing parts with minor
damage for proper function. Make sure that the push-on connection terminals work properly,
that contact is fully established, and that the contact surfaces are clean. All parts have to be
installed correctly and properly conform to all conditions in order for the product to function as
intended. Damaged safety features or functional parts should be properly repaired or replaced by
an approved service shop.
2.8

Data Interface Cover Cap

The dust cap for the interface has to cover the port during operation, in order to keep humidity
and contaminations away.
2.9

Power Supply Specifications

2.9.1

Mains Power Supply

Utility suppliers' wiring requirements, occupational safety rules, applicable standards, and national
codes have to be respected.
When using power distributions on the worksite, rules for the installation of
earth-leakage circuit breakers (RCD) have to be respected, and operation requires
an installed breaker.
Generator or mains power fuse protection should be 16 A (slow blow). The product has to be
protected against rain and humidity.
2.9.2

Generator Power Supply

The required nominal generator capacity as determined by the power supply requirement of
the largest fitting to be welded depends on the power supply specifications, the environment
conditions, and the generator type itself including its control/regulation characteristics.
Nominal output power for a generator 1 phase, 220 - 240 V, 50/60 Hz:
d 20 .............d 160
d 160 ............d 450
Start the generator first, then connect the welding unit. The idle voltage should be set to approx.
240 volts. When turning the generator off, disconnect the welding unit first.
The working output power of the generator decreases by about 10% per 1,000 m of
altitude. During the welding process no other device connected to the same
generator should be operated.
3

Service and Repair

3.1

General

As the product is used in applications that are sensitive to safety considerations, it may be
serviced and repaired only by the manufacturer or its duly authorized and trained partners. Thus,
constantly high standards of operation quality and safety are maintained.
Failure to comply with this provision will dispense the manufacturer from any
warranty and liability claims for the product, including any consequential damage.
When serviced, the unit is upgraded automatically to the technical specifications of the product at
the moment it is serviced, and we grant a three-month functional warranty on the serviced unit.
We recommend having the product serviced at least every twelve months.
In Germany,we recommend using ROTHENBERGER-Service.
3.2

Transport, Storage, Shipment

The product ships in a transport box. The product should be stored in this box, protects the
product from humidity and environmental agents.
When sending the product, it should be placed into the transport box at all times.
3,2 kW
4 kW mechanically regulated
5 kW electronically regulated
ENGLISH 21
