ASSEMBLY INSTRUCTIONS
39. Secure the gazebo to the ground using
stakes (KK).
Hardware Used
Φ8*180 Stake
KK
40. Secure the gazebo to the ground using
stakes (KK).
Hardware Used
Φ8*180 Stake
KK
Moving option 1: move R3 to
top, under R1 or R2
Moving options for top PC panels
Moving option 2: move both
R2 and R3 to top, but should
move them separately, they
can't be moved together
x 4
x 4
24
Moving option 3: move R2 to
top, under R1
